Trunk & fuel door release circuit, convertible for Chevrolet Corvette C6 (2004-2014)

Trunk & fuel door release circuit, convertible

Get access

BATT 1 FUSE 33 BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER (DIC) DISPLAY EXTERIOR REAR COMPARTMENT LID RELEASE SWITCH FUEL DOOR RELEASE SWITCH FUEL DR RELSE RELAY GRY WIRE HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) I/P RELAY BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) INSTRUMENT PANEL CLUSTER (IPC) INTERIOR REAR COMPARTMENT LID RELEASE SWITCH LOGIC LOGIC CLASS 2 SER DATA LT BLU WIRE LT GRN WIRE ORG/BLK WIRE PNK RFA CLASS 2 SER DATA TRUNK REL SW SIG WIRE PNK WIRE PRW/WNDWS TRUNK/FUEL RELSE CIRCUIT BREAKER REAR COMPARTMENT LID LATCH REAR COMPARTMENT LID LOCK CYLINDER KEY SWITCH RED WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH) TAN WIRE TRUNK RELSE FUSE TRUNK RELSE RELAY WHT WIRE WHT/BLK WIRE
