Shift interlock circuit for Chevrolet Corvette C6 (2004-2014)
Shift interlock circuit
5-VOLT REFERENCE
A/T SHIFT LOCK CONTROL SOLENOID
AUTOMATIC TRANSMISSION SHIFT LEVER
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRAKE PEDAL POSITION SENSOR (MOUNTED ON BRAKE PEDAL BRACKET)
BRK POS SENS SIG
BRN WIRE
BTSI SOL/STR WHL LCK FUSE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LOGIC
LOW REFERENCE
LT GRN WIRE
PARK SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
TAN WIRE
WHT WIRE
