Driver power seat circuit for Chevrolet Corvette C6 (2004-2014)
Driver power seat circuit
BLK WIRE
BLU WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY RWD
DRIVER SEAT ADJUSTER SWITCH
DWN FWD REAR VERTICAL MOTOR
DWN UP FRONT VERTICAL MOTOR
FRT DN RR UP
FRT UP
GRN WIRE
HORIZONTAL MOTOR
HOT AT ALL TIMES
I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
NCA WIRE
PWR SEATS MSM CIRCUIT BREAKER
RED WIRE
RR DN FWD
RWD
TAN WIRE
WHT WIRE
YEL WIRE
