Electronic suspension circuit for Chevrolet Corvette C6 (2004-2014)

2501 2500 1206 COMPUTER DATA LINES SYSTEM ABS/ MRRTD FUSE 3 ANTI-LOCK BRAKES SYSTEM EXTERIOR LIGHTS SYSTEM BLK WIRE BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL) BRN WIRE COMPUTER DATA LINES SYSTEM CTRL SW SIG DATA DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ RUN/CRNK RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT SHOCK ABSORBER ACTUATOR (LEFT FRONT SHOCK ABSORBER) LEFT REAR SHOCK ABSORBER ACTUATOR (LEFT REAR SHOCK ABSORBER) LEFT REAR SUSPENSION POSITION SENSOR (LEFT REAR SUSPENSION CONTROL ARM) LF POSI SENS SIG RF POSI SENS SIG LF VOLT REF RF VOLT REF LOGIC LOW REF LR VOLT REF RR VOLT REF LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MRRTD FUSE 13 NCA WIRE ORG/BLK WIRE PERF TRACTION IND PNK 11 2 WIRE PNK WIRE PPL/WHT WIRE RED/WHT WIRE RIGHT FRONT SHOCK ABSORBER ACTUATOR (RIGHT FRONT SHOCK ABSORBER) RIGHT FRONT SUSPENSION POSITION SENSOR (RIGHT FRONT SUSPENSION SHOCK ABSORBER) RIGHT REAR SHOCK ABSORBER ACTUATOR (RIGHT REAR SHOCK ABSORBER) RIGHT REAR SUSPENSION POSITION SENSOR (RIGHT REAR SUSPENSION CONTROL ARM) RR POSI SENS SIG SELECTIVE RIDE IND SPORT IND SPORT LED CTRL TOUR LED CTRL SUSPENSION CONTROL SWITCH (W/O PERFORMANCE PACKAGE SPECIAL COUPE) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TOUR IND UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) W/ PERFORMANCE PACKAGE SPECIAL COUPE W/O PERFORMANCE PACKAGE SPECIAL COUPE
