Chevrolet Corvette C6 (2004-2014) Cruise control circuit, m/t

6.2L (VIN T) 7.0L, 6.2L (VIN W) BODY CONTROL MODULE (BCM) BRAKE PEDAL POSITION SENSOR (MOUNTED ON BRAKE PEDAL BRACKET) BRK STOP POS LAMP SENS SW SIG SIG REF BRN WIRE CLUTCH PEDAL POSITION (CPP) SENSOR COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 5 1 PNK WIRE CRUISE CONTROL SWITCH TURN SIGNAL/MULTI-FUNCTION SWITCH CRUISE CTRL SET/COAST, RESUME/ ACC SW SIGNAL CRUISE SWITCH FUSE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER GRY WIRE HEAD UP DISPLAY (HUD) (IF EQUIPPED) (TOP LEFT SIDE OF DASH) HOT W/ RUN/ CRANK RELAY ENERGIZED HUD CLASS 2 VEHICLE SERIAL DATA SPEED SIG HUD MESSAGE CENTER INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOGIC HIGH SPEED SPEED GMLAN GMLAN SERIAL SERIAL DATA DATA BUS + BUS - LOGIC MESSAGE REQUEST B+ LOW REF LT BLU WIRE LT BLU/BLK WIRE MESSAGE REQUEST B+ NCA WIRE OFF PNK WIRE PPL RADIO SERIAL DATA BUS (+) SERIAL DATA BUS (-) SET- RES+ TAN WIRE TAN/BLK WIRE TAN/WHT WIRE THROTTLE ACTUATOR CONTROL (TAC) MOTOR THROTTLE POSITION (TP) SENSOR UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) VEHICLE IPC CLASS 2 SERIAL DATA SPEED SIG VEHICLE SPEED SENSOR (VSS) (ON TOP RIGHT SIDE OF DIFFERENTIAL) VEHICLE SPEED SIG W/ VARIABLE REAR TIME DAMPING W/O VARIABLE REAR TIME DAMPING WHT WIRE WHT/BLK WIRE YEL WIRE
