Chevrolet Corvette C6 (2004-2014) transmission range sig a Wiring diagram
This page shows the only wiring diagram for the component.transmission range sig a, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission range sig a (1 of 1)
AUTOMATIC TRANSMISSION (6 SPEED A/T)
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE SWITCH FUSE
FROM A/T PIN 3 (DIAGRAM 1 OF 2)
GRN WIRE
GROUND
GRY WIRE
HOT W/RUN/ CRNK RELAY ENERGIZED
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (CENTER OF STEERING COLUMN)
INPUT SPEED SENSOR (ISS)
INTERNAL MODE SWITCH (IMS)
ISS SIG
LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
LOW REF
NCA WIRE
OSS SIG
OUTPUT SPEED SENSOR (OSS)
PIN
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RIGHT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
STOP LAMP SW SIG TRANSMISSION SHIFT SW
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE SIG A
TRANSMISSION RANGE SIG B
TRANSMISSION RANGE SIG C
TRANSMISSION RANGE SIG P
WHT WIRE
YEL WIRE
Go to component -> Transmission circuit (2 of 2) -> TRANSMISSION RANGE SIG A
