Chevrolet Corvette C6 (2004-2014) traffic information receiver wiring diagram
This page shows the only wiring diagram for the component.traffic information receiver, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
traffic information receiver wiring diagram (1 of 1)
A/T PNK WIRE
AUTOMATIC TRANSMISSION SHIFT LEVER (A/T)
BATT 3 FUSE 26
BCK/UP LAMP RELAY
BLK WIRE
BTSI SOL/STR WHL LCK FUSE
CLSTR/HUD FUSE
CRUISE SWTCH FUSE
CTSY/ LAMP FUSE
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DIODE 1
DIODE 2
DR LCK FUSE
DRIVER DOOR PASSENGER UNLATCH DOOR UNLATCH PCB RELAY PCB RELAY
DRIVER HEATED SEAT CONTROL MODULE (W/ FRONT HEATED SEATS)
EX MDL FUSE
EXHAUST TAIL PIPE FLOW VALVE CONTROL MODULE (7.0L, 6.2L (VIN R))
FROM BATT 1 FUSE 33 (DIAGRAM 1 OF 4)
HEAD UP INSTRUMENT PANEL DISPLAY CLUSTER (HUD) (IF EQUIPPED) (IPC)
HTD SEAT/ WPR RLY FUSE
HVAC CONTROL MODULE
HVAC/ PWR SND FUSE
I/P RELAY BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
INADVERTENT LOAD CONTROL PCB RELAY
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSIDE HVAC INSIDE AIR CONTROL REARVIEW TEMPERATURE MODULE MIRROR SENSOR (ISRVM)
ISRVM/ HVAC FUSE
LOGIC
NCA WIRE
PASSENGER HEATED SEAT CONTROL MODULE (W/ FRONT HEATED SEATS)
PNK PNK WIRE
PNK WIRE
RADIO
RDO/S-BAND/ VICS FUSE
REAR FOG/ ALDL/TOP SWTCH FUSE
REAR/FOG RELAY
RED WIRE
RED/WHT WIRE
RLY CTRL
RUN/ CRNK RELAY
STOP LAMP RELAY
STOP/B/U/ LAMPS FUSE 5
TO BATT 5 FUSE 7 (DIAGRAM 3 OF 4)
TO GMLAN RUN/CRNK FUSE (DIAGRAM 3 OF 4)
TONNEAU RELSE FUSE
TRAFFIC INFORMATION RECEIVER
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
W/ DIGITAL RADIO
W/ RR FOG LAMP
W/O DIGITAL RADIO
WHT WIRE
WIPER RUN/ ACC RELAY 42
WIPER/ WASHER SYSTEM
Go to component -> Power distribution circuit (2 of 4) -> TRAFFIC INFORMATION RECEIVER
