Chevrolet Corvette C6 (2004-2014) stop lamp switch sig wiring diagram
This page shows the only wiring diagram for the component.stop lamp switch sig, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop lamp switch sig wiring diagram (1 of 1)
5-VOLT REFERENCE
ABS IND.
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRAKE FLUID LEVEL SWITCH (IN MASTER CYLINDER RESERVOIR)
BRAKE FLUID LVL
BRAKE IND
BRAKE PEDAL POSITION (BPP) SENSOR (MOUNTED ON BRAKE PEDAL BRACKET)
BRN WIRE
BRN/WHT WIRE
CAN CAN BUS BUS LOW HIGH SERIAL SERIAL GRD DATA DATA
COMPUTER DATA LINES SYSTEM
CTRL SWITCH SIGNAL
DK GRN WIRE
DRIVER INFO CENTER (DIC) DISPLAY
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HI SPD GMLAN SER DATA -
IGNITION VOLTAGE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT WHEEL SPEED SENSOR (WSS) (LEFT FRONT WHEEL HUB ASSEMBLIES)
LOGIC
LOW REFERENCE
LT BLU WIRE
ORG/ WIRE
PARK BRAKE SWITCH (LOWER FRONT OF PARK BRAKE HANDLE)
PNK WIRE
POSITION SW SIGNAL
PPL
PRK BRK SW SIG
RIDE CTRL SWITCH SIG
RIGHT FRONT WHEEL SPEED SENSOR (WSS) (RIGHT FRONT WHEEL HUB ASSEMBLIES)
SENS SIG CLASS 2 SERIAL DATA
STOP LAMP SWITCH SIG
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRACTION CONTROL SWITCH (TCS)
TRACTION OFF IND
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> STOP LAMP SWITCH SIG
