Chevrolet Corvette C6 (2004-2014) steering column telescope actuator wiring diagram
This page shows the only wiring diagram for the component.steering column telescope actuator, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
steering column telescope actuator wiring diagram (1 of 1)
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR POSITION SENSOR
DRIVER SEAT HORIZONTAL MOTOR POSITION SENSOR
DRIVER SEAT REAR VERTICAL MOTOR POSITION SENSOR
FRONT DOWN
FRONT UP
FRONT VERTICAL MOTOR
GRY WIRE
HORIZONTAL FORWARD
HORIZONTAL MOTOR
HORIZONTAL REARWARD
LT BLU WIRE
LT GRN WIRE
NCA WIRE
REAR DOWN REAR UP
REAR VERTICAL MOTOR
RED WIRE
RED/WHT WIRE
STEERING COLUMN TELESCOPE ACTUATOR
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit (2 of 2) -> STEERING COLUMN TELESCOPE ACTUATOR
