Chevrolet Corvette C6 (2004-2014) (on top of right frame rail, ground Wiring diagram
This page shows the only wiring diagram for the component.(on top of right frame rail, ground, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (on top of right frame rail, ground (11 of 11)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DELAY SWITCH
FROM WIPER HI/LO RELAY (DIAGRAM 1 OF 2)
GRY WIRE
HDLP WASH FUSE 18
HDLP WASH RELAY 46
HOT AT ALL TIMES
LOGIC
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT GRN WIRE
MIST
OFF
ORG/ WIRE
PNK WIRE
PPL
SENS SIG
SERIAL DATA
TAN/WHT WIRE
UNDER- HOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
W/ WASHER HEADLAMP
W/S WASH FUSE 17
W/S WASH RELAY 36
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH (AT BOTTOM OF WASHER FLUID RESERVOIR)
WINDSHIELD WASHER RELAY CONTROL
WINDSHIELD WASHER SWITCH SIGNAL
WINDSHIELD WIPER SWITCH LOW SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/WASHER SWITCH
WIPER MOTOR PARK SWITCH SIGNAL
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit (2 of 2) -> (ON TOP OF RIGHT FRAME RAIL, GROUND
