Chevrolet Corvette C6 (2004-2014) lumbar inflate ctrl Wiring diagram
This page shows the only wiring diagram for the component.lumbar inflate ctrl, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar inflate ctrl (1 of 1)
BLK WIRE
BOLSTER DEFLATE CTRL
BOLSTER INFLATE CTRL
DRIVER SEAT LUMBAR PUMP/ CONTROL MODULE (UNDER CENTER OF DRIVER SEAT)
DRIVER SEAT LUMBAR SWITCH
DRVR HTD SEAT FUSE
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
LT BLU WIRE
LUMBAR DEFLATE CTRL
LUMBAR INFLATE CTRL
NCA WIRE
PASS HTD SEAT FUSE
PASSENGER SEAT LUMBAR PUMP/ CONTROL MODULE (UNDER CENTER OF PASSENGER SEAT)
PASSENGER SEAT LUMBAR SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RED/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Lumbar circuit -> LUMBAR INFLATE CTRL
