Chevrolet Corvette C6 (2004-2014) k/e b-u low ref k/e left sig k/e rt low ref rear compt lo ref ppl Wiring diagrams
This page contains all the electrical diagrams for the component. k/e b-u low ref k/e left sig k/e rt low ref rear compt lo ref ppl, in which he is found in the car Chevrolet Corvette C6 (2004-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram k/e b-u low ref k/e left sig k/e rt low ref rear compt lo ref ppl (1 of 2)
AJAR CLOSED OPEN
BACKUP KEYLESS ENTRY ANTENNA (RIGHT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK BLU WIRE
DK GRN/WHT WIRE
DOOR AJAR SW
DOOR LATCH
DOOR OPEN SW
DRIVER DOOR LATCH (IN REAR OF DRIVER DOOR)
EXTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES ECM/TCM/ EASY KEY FUSE 11
IGNITION MODE SWITCH
K/E ANT B-U SIG K/E LEFT LOW REF K/E RIGHT SIG
K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL
LATCH (IN REAR OF PASSENGER DOOR) DOOR LATCH
LEFT KEYLESS ENTRY ANTENNA (TOP OF LEFT "B" PILLAR)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK K/E REAR COMPT SIG WIRE
PNK RFA CLASS 2 DATA WIRE
PNK WIRE
PNK/BLK WIRE
PPL
REAR COMPARTMENT KEYLESS ENTRY ANTENNA (BELOW REAR COMPT PULL DOWN ACTUATOR)
RED WIRE
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH)
RIGHT KEYLESS ENTRY ANTENNA (TOP OF RIGHT "B" PILLAR)
RT FRT EXT DR TRUNK REL SW SIG LF FRT EXT DR GROUND
TAN WIRE
TAN/WHT WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Forced entry circuit (1 of 2) -> K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL
Wiring diagram k/e b-u low ref k/e left sig k/e rt low ref rear compt lo ref ppl (2 of 2)
AJAR CLOSED OPEN
BACKUP KEYLESS ENTRY ANTENNA (RIGHT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK BLU WIRE
DK GRN/WHT WIRE
DOOR AJAR SW
DOOR LATCH
DOOR OPEN SW
DRIVER DOOR LATCH (IN REAR OF DRIVER DOOR)
EXTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES ECM/TCM/ EASY KEY FUSE 11
IGNITION MODE SWITCH
K/E ANT B-U SIG K/E LEFT LOW REF K/E RIGHT SIG
K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL
LATCH (IN REAR OF PASSENGER DOOR) DOOR LATCH
LEFT KEYLESS ENTRY ANTENNA (TOP OF LEFT "B" PILLAR)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK K/E REAR COMPT SIG WIRE
PNK RFA CLASS 2 DATA WIRE
PNK WIRE
PNK/BLK WIRE
PPL
REAR COMPARTMENT KEYLESS ENTRY ANTENNA (BELOW REAR COMPT PULL DOWN ACTUATOR)
RED WIRE
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH)
RIGHT KEYLESS ENTRY ANTENNA (TOP OF RIGHT "B" PILLAR)
RT FRT EXT DR TRUNK REL SW SIG LF FRT EXT DR GROUND
TAN WIRE
TAN/WHT WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Power door locks circuit (1 of 2) -> K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL
