Chevrolet Corvette C6 (2004-2014) k/e ant b-u sig k/e left low ref k/e right sig Wiring diagrams

AJAR CLOSED OPEN BACKUP KEYLESS ENTRY ANTENNA (RIGHT SIDE OF DASH) BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN) DK BLU WIRE DK GRN/WHT WIRE DOOR AJAR SW DOOR LATCH DOOR OPEN SW DRIVER DOOR LATCH (IN REAR OF DRIVER DOOR) EXTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ECM/TCM/ EASY KEY FUSE 11 IGNITION MODE SWITCH K/E ANT B-U SIG K/E LEFT LOW REF K/E RIGHT SIG K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL LATCH (IN REAR OF PASSENGER DOOR) DOOR LATCH LEFT KEYLESS ENTRY ANTENNA (TOP OF LEFT "B" PILLAR) LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK K/E REAR COMPT SIG WIRE PNK RFA CLASS 2 DATA WIRE PNK WIRE PNK/BLK WIRE PPL REAR COMPARTMENT KEYLESS ENTRY ANTENNA (BELOW REAR COMPT PULL DOWN ACTUATOR) RED WIRE RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH) RIGHT KEYLESS ENTRY ANTENNA (TOP OF RIGHT "B" PILLAR) RT FRT EXT DR TRUNK REL SW SIG LF FRT EXT DR GROUND TAN WIRE TAN/WHT WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) WHT WIRE

AJAR CLOSED OPEN BACKUP KEYLESS ENTRY ANTENNA (RIGHT SIDE OF DASH) BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN) DK BLU WIRE DK GRN/WHT WIRE DOOR AJAR SW DOOR LATCH DOOR OPEN SW DRIVER DOOR LATCH (IN REAR OF DRIVER DOOR) EXTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ECM/TCM/ EASY KEY FUSE 11 IGNITION MODE SWITCH K/E ANT B-U SIG K/E LEFT LOW REF K/E RIGHT SIG K/E B-U LOW REF K/E LEFT SIG K/E RT LOW REF REAR COMPT LO REF PPL LATCH (IN REAR OF PASSENGER DOOR) DOOR LATCH LEFT KEYLESS ENTRY ANTENNA (TOP OF LEFT "B" PILLAR) LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK K/E REAR COMPT SIG WIRE PNK RFA CLASS 2 DATA WIRE PNK WIRE PNK/BLK WIRE PPL REAR COMPARTMENT KEYLESS ENTRY ANTENNA (BELOW REAR COMPT PULL DOWN ACTUATOR) RED WIRE RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH) RIGHT KEYLESS ENTRY ANTENNA (TOP OF RIGHT "B" PILLAR) RT FRT EXT DR TRUNK REL SW SIG LF FRT EXT DR GROUND TAN WIRE TAN/WHT WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) WHT WIRE
