Chevrolet Corvette C6 (2004-2014) headlight sensor ind Wiring diagram
This page shows the only wiring diagram for the component.headlight sensor ind, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight sensor ind (1 of 1)
AMBIENT LIGHT SENSOR IND
AUTOMATIC DAY/NIGHT MIRROR
BACKUP LAMP PWR
BCK/UP LAMP RELAY
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN/WHT WIRE
BUTTON BACK LIGHTING
CRNK RELAY
DAY/NIGHT MIRROR LOW REF
DAY/NIGHT MIRROR SIG AUTOMATIC DAY/NIGHT MIRROR
DK GRN/WHT WIRE
DRIVER OUTSIDE REARVIEW MIRROR
EMERGENCY IND
EMERGENCY SWITCH
GRY WIRE
HEADLIGHT SENSOR IND
HOT AT ALL TIMES
IGN 1 VOLT GND
INSIDE REARVIEW MIRROR
ISRVM/ HVAC FUSE
KEYPAD
KEYPAD GREEN LED IND
KEYPAD GREEN LED SIG
KEYPAD RED WIRE
KEYPAD SIG
KEYPAD SPLY VOLT
LED SIG
LEFT
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ONSTAR BUTTON ASSEMBLY
ONSTAR IND
ONSTAR SWITCH
ORG/ WIRE
PASSENGER AIR BAG OFF IND
PASSENGER AIR BAG ON IND
PHONE IND
PHONE SWITCH
PNK WIRE
RED LED IND WIRE
REVERSE LAMPS FUSE
REVERSE RUN/ CRANK LAMP RLY RLY CTRL CTRL
RIGHT
RUN WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN/BLK WIRE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (W/ ONSTAR) (IN RIGHT REAR COMPT)
WHT WIRE
YEL/BLK WIRE
Go to component -> Automatic day/night mirror circuit -> HEADLIGHT SENSOR IND
