Chevrolet Corvette C6 (2004-2014) hazard warning switch wiring diagram
This page shows the only wiring diagram for the component.hazard warning switch, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
hazard warning switch wiring diagram (1 of 1)
BASE UPLEVEL
BLK WIRE
DATA LINK CONNECTOR (DLC)
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LATCH
DRIVER DRIVER DOOR DOOR LOCK LOCK INDICATOR SWITCH
DRIVER EXTERIOR DOOR HANDLE I/P SWITCH DIMMER SWITCH
DRIVER INTERIOR DOOR HANDLE SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR PUMP/ CONTROL MODULE
DRIVER WINDOW SWITCH
EXCEPT CONVERTIBLE
FOLDING FOLDING TOP TOP VALVE 2 VALVE 3
FOLDING TOP PUMP/ MOTOR ASSEMBLY
FOLDING TOP VALVE 1
FUEL DOOR RELEASE ACTUATOR
FUEL DOOR RELEASE SWITCH
HAZARD WARNING SWITCH
HORN SWITCH
IGNITION MODE SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
INTERIOR REAR COMPARTMENT LID RELEASE SWITCH
LEFT STEERING WHEEL CONTROL SWITCH
NCA WIRE
REAR COMPARTMENT LID LATCH
REAR WINDOW DEFOGGER GRID
STEERING ANGLE SENSOR TURN SIGNAL/ MULTI-FUNCTION SWITCH
SWITCH BREAKOUT)
W/ HEAD UP DISPLAY
YAW, LATERAL ACCELEROMETER SENSOR
Go to component -> Ground distribution circuit (2 of 4) -> HAZARD WARNING SWITCH
