Chevrolet Corvette C6 (2004-2014) drvr dr lock actuator unlock ctrl Wiring diagram
This page shows the only wiring diagram for the component.drvr dr lock actuator unlock ctrl, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drvr dr lock actuator unlock ctrl (1 of 1)
BACKUP LAMP SPLY VOL
BATT 3 FUSE 26
BATT 5 FUSE 7
BATTERY
BATTERY BATTERY
BATTERY BATTERY BATTERY
BATTERY VOLTAGE + BATTERY
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
COURTESY LAMP SUPPLY VOLT DOOR LOCK ACTUATOR UNLOCK CTRL
DK GRN WIRE
DOOR LOCKS SYSTEM
DRVR DR LOCK ACTUATOR UNLOCK CTRL
EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
LOGIC
LR STOP/TURN LAMP SUPPLY VOLTAGE COURTESY LAMP CTRL
LT GRN WIRE
ORG/ WIRE
PNK IGN 1 VOLTAGE WIRE
PNK IGN MODE SW LED SPLY VOL WIRE
PNK PNK IGN 1 VOLTAGE WIRE
PNK WINDSHIELD WASHER SW SIG WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
RED/BLK WIRE
RED/WHT WIRE
RR STOP/TURN LAMP SUPPLY VOLTAGE
STOP/B/U/ LAMPS FUSE 5
TAN WIRE
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (2 of 4) -> DRVR DR LOCK ACTUATOR UNLOCK CTRL
