Chevrolet Corvette C6 (2004-2014) driver wndo express sig Wiring diagram
This page shows the only wiring diagram for the component.driver wndo express sig, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver wndo express sig (1 of 1)
20 19 1440 1047 B+ PDM CLASS 2 SER DATA COMPUTER DATA LINES SYSTEM
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER WINDOW MOTOR (DRIVER'S DOOR)
DRIVER WINDOW SWITCH
DRIVER WNDO DOWN SIGNAL
DRIVER WNDO EXPRESS SIG
DRIVER WNDO UP SIGNAL
EXPRESS DN
EXPRESS UP
GROUND
GRY WIRE
HOT AT ALL TIMES DRIV DR SWTCH FUSE
LF UP CTRL
LOGIC
PASS WNDO EXPRESS SIG PASS WNDO DOWN SIGNAL
PASS WNDO UP SIGNAL
PASSENGER DOOR CONTROL MODULE (BOTTOM CENTER OF PASSENGER DOOR)
PASSENGER WINDOW SWITCH
POWER WINDOW MOTOR FRONT PASSENGER UP SIG
PPL
PPL POWER WINDOW SWITCH RT FRONT EXPRESS SIG
PWR WIND MTR LF DOWN CTRL PWR WIND MTR
RED WIRE
RED/WHT WIRE
SER DATA
SERIAL DATA
TAN WIRE
WHT WIRE
Go to component -> Power windows circuit -> DRIVER WNDO EXPRESS SIG
