Chevrolet Corvette C6 (2004-2014) dr open sw sig Wiring diagrams
This page contains all the electrical diagrams for the component. dr open sw sig, in which he is found in the car Chevrolet Corvette C6 (2004-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dr open sw sig (1 of 2)
19 24 25 26 SERIAL DATA DR LOCK IND HANDLE SW SIG HANDLE SW SIG
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN WIRE
CLASS 2 (BCM) SECURITY IND
CLASS 2 DATA
COUPE
DK BLU WIRE
DOOR LATCH CTRL
DOOR PANEL)
DR AJAR SW SIG
DR LCK FUSE
DR OPEN SW SIG
DRIVER DOOR CONTROL MODULE (BOTTOM CENTER OF DRIVER DOOR)
DRIVER DOOR LOCK INDICATOR (IN UPPER REAR OF DRIVER DOOR TRIM PANEL)
DRIVER DOOR UNLATCH PCB RELAY
DRIVER EXTERIOR DOOR HANDLE SWITCH (IN UPPER REAR OF DRIVER DOOR)
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER INTERIOR DOOR HANDLE SWITCH (IN CENTER OF DRIVER DOOR PANEL)
DRIVER UN- LOCK DOOR LOCK LOCK SWITCH
DRIVER WINDOW SWITCH
GRY WIRE
GRY/BLK WIRE
HORN REL CNTRL
HORNS SYSTEM
HOT AT ALL TIMES
IGN
IGN 1 VOLT
IGN SWITCH/ INTR DRIV DR SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
IPC CLASS 2 SERIAL DATA
LCD LAMP BATTERY GROUND UNLOCK SIG LOCK SIG MEMORY 1 MEMORY 2 SERIAL DATA
LOGIC
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MEMORY SYSTEMS
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER DOOR CONTROL MODULE (BOTTOM CENTER OF PASSENGER DOOR)
PASSENGER DOOR LOCK INDICATOR (IN UPPER REAR OF
PASSENGER DOOR TRIM PANEL)
PASSENGER DOOR UNLATCH PCB RELAY
PASSENGER EXTERIOR DOOR HANDLE SWITCH (IN UPPER REAR OF PASSENGER DOOR)
PASSENGER INTERIOR DOOR HANDLE SWITCH (IN CENTER OF PASSENGER
PASSENGER UN- LOCK DOOR LOCK LOCK SWITCH
PK LAMP RLY
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL/WHT WIRE
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT LID PULLDOWN ACTUATOR (CENTER REAR OF COMPT LID)
RED/WHT WIRE
SNSR FUSE FUSE
TAN WIRE
TAN/WHT WIRE
TRK AJAR SW SIG
WHT WIRE
Go to component -> Forced entry circuit (2 of 2) -> DR OPEN SW SIG
