Chevrolet Corvette C6 (2004-2014) 55 56 38 class 2 ser data rf trn sig vlt lf trn sig vlt Wiring diagram
This page shows the only wiring diagram for the component.55 56 38 class 2 ser data rf trn sig vlt lf trn sig vlt, which is found in the car Chevrolet Corvette C6 (2004-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 55 56 38 class 2 ser data rf trn sig vlt lf trn sig vlt (1 of 1)
5 67 66 PRK LMP SW ON SIG RT TRN SIG SW LT TRN SIG SW
55 56 38 CLASS 2 SER DATA RF TRN SIG VLT LF TRN SIG VLT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRAKE PEDAL POSITION (BPP) SENSOR (MOUNTED ON BRAKE PEDAL BRACKET)
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SIDE MARKER LAMP
LEFT PARK/ TURN TURN PARK SIGNAL LAMP
LOGIC
LOW REF BRK POS SENS SIG HAZARD SW SIG
LT BLU WIRE
LT BLU/WHT WIRE
LT DK
LT GRN WIRE
OFF AUTO
PARK HEAD
PARK LAMP RELAY 37
PK LAMPS FUSE 8
PRK LMP RLY CNTL
RED WIRE
RED/WHT WIRE
RIGHT FRONT SIDE MARKER LAMP
RIGHT PARK/ TURN PARK SIGNAL LAMP
RR LMP SUPPLY VLT LR LMP SUPPLY VLT
STOP/ B/U/ LAMPS FUSE 5
STP LMP SW SIG
TAN WIRE
TURN
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> 55 56 38 CLASS 2 SER DATA RF TRN SIG VLT LF TRN SIG VLT
