Chevrolet Corvette C6 (2004-2014) 1 27 28 park/neutral signal gmlan serial data bus - gmlan serial data bus + wiring diagram

1 19 SERIAL DATA (+) SERIAL DATA (-) 1 27 28 PARK/NEUTRAL SIGNAL GMLAN SERIAL DATA BUS - GMLAN SERIAL DATA BUS + A/T TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR ACCESSORY VOLTAGE AUTOMATIC TRANSMISSION (6 SPEED A/T) AUTOMATIC TRANSMISSION FLUID PRESSURE MANUAL VALVE POSITION SWITCH B+ GROUND BLK/WHT WIRE BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL) CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DRIVER INFORMATION CENTER (DIC) DISPLAY ECM/TCM/ EASY KEY FUSE 56 ENGINE CONTROLS GMLAN (ECM) GRY WIRE HOT AT ALL TIMES HOT W/RUN/ CRNK RELAY ENERGIZED IGN LOGIC LOGIC INSTRUMENT PANEL CLUSTER (IPC) LOW REF ORG/BLK WIRE PC 1 SOLENOID PC 2 SOLENOID PC 3 SOLENOID PC 4 SOLENOID PC 5 SOLENOID PNK WIRE POWER DISTRIBUTION SYSTEM POWER POWER DISTRIBUTION DISTRIBUTION SYSTEM SYSTEM PRESSURE CONTROL (PC) SOLENOID VALVE 1 PRESSURE CONTROL (PC) SOLENOID VALVE 2 PRESSURE CONTROL (PC) SOLENOID VALVE 3 PRESSURE CONTROL (PC) SOLENOID VALVE 4 PRESSURE CONTROL (PC) SOLENOID VALVE 5 RED/WHT WIRE SHIFT SOLENOID (SS) VALVE 1 SHIFT SOLENOID (SS) VALVE 2 SS 1 SS 2 STOP LAMP SW SIG SYSTEM TAN WIRE TAN/BLK WIRE TCCPC SOLENOID TCM/ TRANS FUSE 1 TFP 1 TFP 3 TFP 4 TFP 5 TFT TO A/T INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2) TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) UPSHIFT IND WHT WIRE YEL WIRE
