Warning system circuits for Chevrolet Corvette C5 (1997-2004)
Warning system circuits
ALC HDLP RELAY 44
BASE SEAT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
DK BLU WIRE
DOOR CONTROL MODULE
DRIVER DOOR LATCH
DRIVER SEAT BELT SWITCH
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE 19
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
PNK WIRE
SEAT BELT INDICATOR
SPLICE PACK
SPORT SEAT
STAR CONNECTOR 1 (LEFT SIDE OF BCM)
TAN WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
