Folding top lid release circuit for Chevrolet Corvette C5 (1997-2004)
Folding top lid release circuit
ANTI-THEFT SYSTEM
BCM CALSS 2 SERIAL DATA
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON THE TOE BOARD, IN RIGHT FOOTWELL)
COMPUETR DATA LINES SYSTEM
CON TOP COVER AJAR SW IN
CON TOP REL COVER SW IN
CON TOP RLY COVER REL CTRL
DK BLU WIRE
DK GRN WIRE
FOLDING TOP LID LATCH (ON STOWAGE LID EXTENSION BRACKET)
FOLDING TOP RELEASE SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
LT GRN WIRE
NCA WIRE
PPL
PPL LT
RED WIRE
SPLICE PACK 302 (FRONT OF RIGHT QUARTER PANEL)
TONN REL FUSE 17
TONN REL RELAY 41
