Power door lock circuit for Chevrolet Corvette C5 (1997-2004)

1 3 10 13 14 BATT SERIAL DATA DOOR AJAR KEY SIGNAL GROUND 15 14 9 UNLOCK INPUT LOCK INPUT GROUND 5 3 LOCK 9 14 15 GROUND LOCK INPUT UNLOCK INPUT 9 14 LOCK AJAR SWITCH BATT SERIAL DATA DOOR AJAR KEY SIGNAL GROUND BATT UNLOCK OUTPUT BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT FOOTWELL) BRN WIRE COMPUTER DATA LINK SYSTEM DCM/L FUSE 33 DCM/R FUSE 30 PWR FDR FUSE 31 DOOR AJAR DOOR AJAR DOOR AJAR DRIVER DOOR LATCH DRIVER DOOR MODULE (INSIDE LEFT DOOR) DRIVER DOOR SWITCH GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HVAC CON FUSE 27 INSTRUMENT PANEL FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) KEY SWITCH LOCK MOTOR LOCK OUTPUT GROUND LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER DOOR LATCH PASSENGER DOOR MODULE (INSIDE RIGHT DOOR) PASSENGER DOOR SWITCH PNK WIRE PWR FDL FUSE 34 RED/BLK WIRE REMOTE CONTROL DOOR LOCK RECEIVER (ON LEFT SIDE OF REAR COMPARTMENT) SPLICE PACK SPLICE PACK 208 (BEHIND RIGHT SIDE OF DASH) TAN WIRE UNLOCK
