Compressor circuit for Chevrolet Corvette C5 (1997-2004)
Compressor circuit
43 18 14 45 17 RELAY CTRL A/C ON PRESS SIG
60 58 SENS GND DATA LINE
A/C CLU RELAY
A/C COMPRESSOR CLUTCH
A/C FUSE 24
A/C REFRIGERANT PRESSURE SENSOR (ATTACHED TO THE A/C HIGH SIDE LINE)
A/C REQ
BLK WIRE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT IN RUN OR START
HVAC CONTROL MODULE (W/ AUTO A/C)
HVAC CONTROL MODULE (W/ MANUAL A/C)
NCA WIRE
PPL
RED/BLK WIRE
SERIAL DATA
SPLICE PACK
STAR CONNECTOR 1 (IN DASH HARNESS)
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
