Chevrolet Corvette C5 (1997-2004) under- hood fuse block wiring diagram
This page shows the only wiring diagram for the component.under- hood fuse block, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
under- hood fuse block wiring diagram (1 of 1)
ALC PRK LP RELAY
ALC RELAY LFT DRL CTRL
ANTI-LOCK BRAKES SYSTEM
APPROACH MINI FUSE 2
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN WIRE
CENTER HIGH MOUNT STOP LAMP (CHMSL)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRL LEFT RELAY
DRL RIGHT RELAY
GRY/BLK WIRE
HAZARD SW
HAZARD WARNING SWITCH
HAZT/SG MINI FUSE 15
HEAD
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT REAR MARKER LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMPS
LFT TURN IN
LICENSE LAMPS
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
NCA WIRE
OFF
ORG/ WIRE
ORG/BLK WIRE
PARK
PK/TLP MINI FUSE 6
PNK WIRE
PPL
PPL FLASHER
RADIO MODULE)
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMPS RIGHT REAR MARKER LAMP
RT TURN IN
RT TURN IN LFT TURN IN RT DRL CTRL
SPLICE PACK 100 (REAR OF RIGHT FRONT WHEELWELL)
SPLICE PACK 102 (UNDER RIGHT HEADLAMP, TAPED TO HARNESS)
SPLICE PACK 201 (AT LEFT KICK PANEL)
SPLICE PACK 400 (REAR OF VEHICLE, TAPED TO HARNESS NEAR BACK-UP LAMPS)
STOPLAMP SWITCH
STP/HAZ MINI FUSE 8
TURN SIGNAL SWITCH
UNDER- HOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit -> UNDER- HOOD FUSE BLOCK
