Chevrolet Corvette C5 (1997-2004) star connector 1 (near left side of Wiring diagram
This page shows the only wiring diagram for the component.star connector 1 (near left side of, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram star connector 1 (near left side of (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN WIRE
BRN/WHT WIRE
C/LALDL FUSE 29
CD CHANGER REMOTE PLAY- BACK DEVICE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER DOOR CONTROL MODULE BOTTOM CENTER, REAR OF SPEAKER)
GRY WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE (W/ AUTOMATIC TEMPERATURE CONTROL) (UNDER RADIO)
I/P FUSE BLOCK (IN RIGHT FOOTWELL, MOUNTED TO TOE BOARD)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (AT RIGHT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER DOOR CONTROL MODULE (IN LOWER CENTER OF PASSENGER DOOR)
PNK WIRE
PPL
PPL 2 1
RADIO
REMOTE CONTROL DOOR LOCK RECEIVER (LEFT SIDE OF REAR COMPT)
SPLICE PACK 201 (LEFT KICK PANEL)
SPLICE PACK 208 (BEHIND RIGHT SIDE OF DASH)
STAR CONNECTOR 1 (NEAR LEFT SIDE OF
TAN WIRE
W/ MEMORY SEAT ONLY (BELOW BATTERY)
W/ MULTIPLE COMPACT DISC PLAYER
W/O MULTIPLE COMPACT DISC PLAYER
WHT WIRE
Go to component -> Computer data lines -> STAR CONNECTOR 1 (NEAR LEFT SIDE OF
