Chevrolet Corvette C5 (1997-2004) seat relay center driver Wiring diagram
This page shows the only wiring diagram for the component.seat relay center driver, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat relay center driver (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID
AUTO A/C
BANK 1 SENSOR 1 BANK 1 SENSOR 1
BANK 2 SENSOR 1
BANK 2 SENSOR 2
BASE SEAT
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY (MANUAL A/C)
BODY CONTROL MODULE (BCM)
BOSE RELAY 45
CIGAR LIGHTER
DEFOGGER GRID
ELECTRONIC BRAKE/ CONTROL MODULE (EBTCM)
ENGINE OIL LEVEL SWITCH
F/ PMP MICRO- RELAY 35
FOOTWELL PANEL COURTESY LAMP- RIGHT
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
HVAC CONTROL MODULE
I/P COMPARTMENT LAMP
IGN MINI- RELAY 42
IGNITION COIL/ MODULE 1
IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 3
IGNITION COIL/ MODULE 4
IGNITION COIL/ MODULE 5
IGNITION COIL/ MODULE 6
IGNITION COIL/ MODULE 7
IGNITION COIL/ MODULE 8
IGNITION SWITCH
MANUAL A/C
MANUAL A/C AUTO A/C
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
PASSENGER DOOR MODULE (PDM) DOOR LATCH- RIGHT
POWERTRAIN CONTROL MODULE (PCM)
SEAT BELT SWITCH- DRIVER
SEAT CONTROL MODULE DRIVER
SEAT PUMP DRIVER
SEAT RELAY CENTER DRIVER
SPLICE PACK 122 (UNDER LEFT REAR CORNER OF BATTERY TRAY)
SPLICE PACK 202 (RIGHT KICK PANEL)
SPORT SEAT
THROTTLE ACTUATOR CONTROL (TAC) MODULE
VANITY MIRROR LAMP- LEFT VANITY MIRROR LAMP- RIGHT INSIDE REARVIEW MIRROR
W/ MEMORY
W/O MEMORY
WIRE END TAPED TO INSTRUMENT PANEL HARNESS
Go to component -> Ground distribution circuit (2 of 3) -> SEAT RELAY CENTER DRIVER
