Chevrolet Corvette C5 (1997-2004) rr defog fuse 48 Wiring diagram
This page shows the only wiring diagram for the component.rr defog fuse 48, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr defog fuse 48 (1 of 1)
450 267 GROUND MIRROR HTR CTRL
AUTO A/C
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE/ HARDTOP
COUPE
DATA LINE
DEFOG ENABLE
DEFOG IND
DEFOG RELAY CTRL
DEFOG REQUEST
DEFOGGER GRID
DEFOGGER IND
DRIVER DOOR MODULE (DDM) (IN LOWER CENTER OF DRIVER'S DOOR)
DRIVER OUTSIDE REARVIEW MIRROR
GROUND
HOT AT ALL TIMES
HOT IN ON HVAC FUSE 18
HVAC CONTROL MODULE
I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
IGN
IGNITION
LT GRN WIRE
MAN A/C
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MODULE (PDM) (IN LOWER CENTER OF PASSENGER'S DOOR)
PASSENGER OUTSIDE REARVIEW MIRROR
POWER ANTENNA SYSTEM
POWER DISTRIBUTION SYSTEM
PPL
PPL (DASH HARN, NEAR BLWR MTR BREAKOUT)
PPL DEFOG SIGNAL
REAR DEFOGGER CAPACITOR
REAR DEFOGGER INDUCTOR 1
REAR DEFOGGER INDUCTOR 2
REAR DEFOGGER SWITCH
RR DEFOG FUSE 48
RR DEFOG RELAY 46
SPLICE PACK
STAR CONNECTOR 1 (LEFT OF BODY CONTROL MODULE (BCM))
STAR CONNECTOR 2 (LEFT OF BODY CONTROL MODULE (BCM))
TAN WIRE
WHT WIRE
Go to component -> Defogger circuit -> RR DEFOG FUSE 48
