Chevrolet Corvette C5 (1997-2004) rf sol low rf sol high rtd relay wiring diagram
This page shows the only wiring diagram for the component.rf sol low rf sol high rtd relay, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rf sol low rf sol high rtd relay wiring diagram (1 of 1)
ABS SYSTEM
ABSTRNS FUSE 5
ANTI-LOCK BRAKE SYSTEM
BLK WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (AT LEFT FRONT SIDE OF ENGINE COMPT)
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
IGNITION
INSTRUMENT CLUSTER VSS SIGNAL
LEFT FRONT SHOCK ABSORBER SOLENOID (ON BOTTOM OF LEFT FRONT SHOCK)
LEFT FRONT SUSPENSION POSITION SENSOR (ATTACHED TO SUSPENSION CONTROL ARM)
LEFT REAR SHOCK ABSORBER SOLENOID (ON BOTTOM OF LEFT REAR SHOCK)
LEFT REAR SUSPENSION POSITION SENSOR (ATTACHED TO SUSPENSION CONTROL ARM)
LF SOL LOW LF SOL HIGH
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
PERF
PNK/BLK WIRE
PNK/WHT WIRE
PPL (DASH HARN, NEAR BLOWER MOTOR CONTROL MODULE CONNECTOR BREAKOUT) PPL 2
PPL/WHT WIRE
REAL TIME DAMPING (RTD) RELAY 41
RED WIRE
RED/BLK WIRE
RF SOL LOW RF SOL HIGH RTD RELAY
RIGHT FRONT SHOCK ABSORBER SOLENOID (ON BOTTOM OF RIGHT FRONT SHOCK)
RIGHT FRONT SUSPENSION POSITION SENSOR (ATTACHED TO SUSPENSION CONTROL ARM)
RIGHT REAR SHOCK ABSORBER SOLENOID (ON BOTTOM OF RIGHT REAR SHOCK)
RIGHT REAR SUSPENSION POSITION SENSOR (ATTACHED TO SUSPENSION CONTROL ARM)
RTD FUSE 51
RTD FUSE 7
SEL RIDE REF
SERIAL DATA
SOL SUPPLY
SOLID
SPORT
STAR CONNECTOR 1 (NEAR LEFT SIDE OF BCM)
STATE
TAN/WHT WIRE
TOUR
TRACTION/ SUSPENSION CONTROL SWITCH
UNDERHOOD FUSE BLOCK (ON RIGHT REAR OF ENGINE COMPT)
Go to component -> Electronic suspension circuit -> RF SOL LOW RF SOL HIGH RTD RELAY
