Chevrolet Corvette C5 (1997-2004) pwr dl fuse 34 Wiring diagram

AUTOMATIC A/C AUXILIARY POWER DROP CONNECTOR BASE SEAT BLK WIRE BLOWER MOTOR RELAY (MANUAL A/C) BOSE RELAY 45 BLO MOT FUSE 51 BOSE FUSE 28 BOSE SIGNAL PROCESSOR C/LTR FUSE 7 CD CHANGER- REMOTE PLAYBACK DEVICE CIGAR LIGHTER CNSL CIG FUSE 1 CONT- ACT DCM L FUSE 33 DCM R FUSE 30 DRIVER DOOR MODULE (DDM) DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT CONTROL MODULE (SCM) DRIVER SEAT RELAY CENTER F/TNKDR FUSE 32 FROM FUSE BLOCK-UNDERHOOD (DIAGRAM 1 OF 4) FROM RDO/CD FUSE 5 (DIAGRAM 2 OF 4) FROM STARTER FUSE 52 (DIAGRAM 2 OF 4) FUEL DOOR LOCK RELEASE SWITCH FUSE 47 FUSE 50 HTCHTRK REL RELAY 39 FUSE BLOCK-I/P (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) HVAC CONTROL MODULE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) HVACCON FUSE 27 LUMBAR FUSE 3 MANUAL A/C NCA WIRE ORG BLK WIRE ORG/ WIRE PASENGER DDOR MODULE (PDM) PASSENGER SEAT PUMP PASSENGER SEAT PUMP PASSENGER SEAT RELAY CENTER PASSENGER SEAT RELAY CENTER PASSENGER SEAT ADJUSTER SWITCH PWR DL FUSE 34 PWR ST/ DRV CIRCUIT BREAKER 35 PWR ST/PAS CIRCUIT BREAKER 36 PWRFDR FUSE 31 RADIO RADIO POWER ANTENNA (CONVERTIBLE) RDO/ANT FUSE 24 RDO/CD FUSE 5 RED WIRE REMOTE PLAYBACK DEVICE- CD CHANGER (DEALER INSTALLED) RRDEFOG FUSE 48 SCM L FUSE 4 RRDEFOG RELAY 44 SPLICE PACK 201 (LEFT KICK PANEL) SPLICE PACK 202 (RIGHT KICK PANEL) SPORT SEAT SPORT SEAT BASE SEAT STARTER FUSE 52 STOP- LAMP SWITCH HAZARD SWITCH STP/HAZ FUSE 8 THEFT DETERRENT RELAY TO BLO MOT FUSE 51 (DIAGRAM 2 OF 4) TO IGNITION SWITCH (DIAGRAM 3 OF 4) TO LUMBAR MINI FUSE 3 (DIAGRAM 2 OF 4) TO PK T/LP FUSE 6 (DIAGRAM 3 OF 4) TONN REL FUSE 17 TONN REL RELAY 41 W/CD PLAYER W/O CD PLAYER WIRE ENDS TAPED TO I/P HARNESS
