Chevrolet Corvette C5 (1997-2004) pass-key in pass key rtn serial data trunk rly ctrl horn rly Wiring diagram

A/T ACCY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (MOUNTED ON THE TOE BOARD, IN RIGHT FRONT FOOTWELL) BULB TEST CRK FUSE 14 DK BLU WIRE DK GRN WIRE DK/BLU WIRE DRIVER DOOR EXTERIOR LIGHTS SYSTEM (BACK-UP LIGHTS CIRCUIT) EXTERIOR LIGHTS SYSTEM (DRL RELAYS) F/TNKDR FUSE 32 FOG LAMP SWITCH/ REAR COMPARTMENT LID RELEASE SWITCH FOLDING TOP AJAR INDICATOR SWITCH GROUND GROUND LT DRL RLY STARTER ENABLE KEY OUT GRY WIRE GRY/BLK WIRE HORNS SYSTEM (HORN RELAY) HOT AT ALL TIMES HOT IN ON AND START HTCHTRK RLY RELAY IGNITION KEY IGNITION KEY LOCK CYLINDER IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) SECURITY INDICATOR INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) IPC FUSE KEY SW IN LEFT DOOR AJAR INDICATOR SWITCH LEFT DOOR KEY SWITCH LOCK OFF LT BLU WIRE LT DOOR AJAR LT GRN WIRE LT GRN/BLK WIRE M/T MODULE (BOTTOM OF LEFT DOOR) NCA WIRE ORG/ WIRE ORG/BLK WIRE PASS-KEY IN PASS KEY RTN SERIAL DATA TRUNK RLY CTRL HORN RLY PASSENGER DOOR MODULE (BOTTOM OF RIGHT DOOR) PNK WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) PPL PPL/WHT WIRE REAR COMPARTMENT LID AJAR SWITCH RED WIRE RED/BLK WIRE RESISTOR PELLET RIGHT DOOR AJAR INDICATOR SWITCH RIGHT DOOR KEY SWITCH RT DOOR AJAR RUN WIRE SERIAL DATA SPLICE PACK 201 (LEFT KICK PANEL) SPLICE PACK 202 (RIGHT KICK PANEL) SPLICE PACK 302 (FRONT OF RIGHT QUARTER PANEL) STAR CONNECTOR 1 (IN INSTRUMENT PANEL HARNESS) STARTER FUSE 52 STARTING/ CHARGING SYSTEM (STARTER) TAN WIRE THEFT DETERRENT RELAY (IN RIGHT FOOTWELL, ABOVE BCM) WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
