Chevrolet Corvette C5 (1997-2004) low speed relay ctrl wiring diagram
This page shows the only wiring diagram for the component.low speed relay ctrl, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
low speed relay ctrl wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
COOL FAN 1 RELAY
COOL FAN 2 RELAY
COOL FAN 3 RELAY
COOLFAN 2 FUSE 46
COOLFAN 3 FUSE 14
COOLING FAN (LEFT)
COOLING FAN (RIGHT)
DK BLU WIRE
DK GRN WIRE
ECT SENSOR
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF ENGINE, BELOW GENERATOR)
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LOW SPEED RELAY CTRL
LT BLU WIRE
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) COOLFAN 1 FUSE 49
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> LOW SPEED RELAY CTRL
