Chevrolet Corvette C5 (1997-2004) ign relay 42 Wiring diagrams
This page contains all the electrical diagrams for the component. ign relay 42, in which he is found in the car Chevrolet Corvette C5 (1997-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ign relay 42 wiring diagram (1 of 2)
1 TO 4 IND
1 TO 4 IND CTRL
BLK WIRE
FUSE 19
GRY WIRE
HOT AT AL TIMES
HOT IN ON OR START
I/P FUSE BLOCK (RIGHT FRONT FOOTWELL)
IGN RELAY 42
IGNITION
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE 19
LT GRN WIRE
PCM FUSE 16
PNK EVAPORATIVE EMMISSIONS VENT SLENOID WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (REAR OF RIGHT FRONT FENDER)
REV GEAR INHIBIT SOL CTRL
REVERSE INHIBIT SOLENOID (TOP LEFT OF TRANSMISSION)
SKIP SHIFT SOL CTRL
SKIP SHIFT SOLENOID (LEFT SIDE OF TRANSMISSION)
SOLID STATE
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
Go to component -> 5.7l vin g, m/t circuit -> IGN RELAY 42
ign relay 42 wiring diagram (2 of 2)
ABS ELEC FUSE 53
ABS FUSE 52
AIR PMP FUSE 50
AIR PMP RELAY 33
APROACH FUSE 2
AUTOMATIC TRANSMISSION (A/T)
BACKUP LP RELAY 38
BATTERY
BLK/ WHT WIRE
COOL FAN 1 RELAY 45
COOL FAN 2 RELAY 43
COOLFAN 2 FUSE 46
CRUISE CONTROL RELEASE SWITCH (M/T)
DK GRN WIRE
DRL L RELAY 40
DRL R RELAY 38
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ELECTRONIC SUSPENSION CONTROL (ESC) MODULE
ENG IGN 1 FUSE 19
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
FOG LAMP/REAR COMPARTMENT LID RELEASE SWITCH
FOG LP FUSE 6
FOG LP RELAY 39
FROM COOL FAN 2 FUSE 46 (DIAGRAM 1 OF 4)
FROM COOL FAN FUSE 49 (DIAGRAM 1 OF 4)
FROM F/PMP FUSE 13 (DIAGRAM 4 OF 4)
FROM IGN RELAY 42 (DIAGRAM 1 OF 4)
FUSE 49
FUSE BLOCK- UNDERHOOD (ON RIGHT REAR OF ENGINE COMPART- MENT)
FUSE BLOCK- UNDERHOOD (ON RIGHT REAR OF ENGINE COMPARTMENT)
FUSE BLOCK-I/P (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
FUSIBLE LINK (10 GA-RUST)
FUSIBLE LINK (20 GA-GRAY)
GENERATOR
HDLPMOTLH FUSE 4
HDLPMOTRH FUSE 3
HEADLAMP DOOR CONTROL MODULE
HORN FUSE 11
HORN RELAY 36
HORNS ASSEMBLY
IGN RELAY 42
LEFT FOG LAMP
MASS AIR FLOW (MAF SENSOR)
NCA WIRE
ORG/ WIRE
PCM B FUSE 23
PCM FUSE 16
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PPL
RED WIRE
RIGHT FOG LAMP
RTD FUSE 51
RTD FUSE 7
RTD RELAY 41
SKIP SHIFT SOLENOID (M/T) REVERSE INHIBIT SOLENOID (M/T)
STARTER
STOPLAMP SWITCH SECONDARY AIR INJECTION (AIR) SOLENOID
TO APROACH FUSE 2 (DIAGRAM 1 OF 4)
TO ENG IGN 1 FUSE 19 (DIAGRAM 1 OF 4)
TO FUSE BLOCK-I/P (DIAGRAM 2 OF 4)
TO IGN RELAY 42 (DIAGRAM 1 OF 4)
TO THROT-CONT FUSE 17 (DIAGRAM 4 OF 4)
WHT/ BLK WIRE
Go to component -> Power distribution circuit (1 of 4) -> IGN RELAY 42
