Chevrolet Corvette C5 (1997-2004) hot in on btsi bu fuse 21 Wiring diagram
This page shows the only wiring diagram for the component.hot in on btsi bu fuse 21, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on btsi bu fuse 21 (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID (MOUNTED ON BRACKET, IN FRONT OF BRAKE PEDAL)
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL)
BRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES PK T/LP MINIFUSE 6
HOT IN ON BTSI BU FUSE 21
I/P FUSE BLOCK
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH
PRNDL
SPLICE PACK
STOPLAMP SWITCH
Go to component -> Shift interlock circuit -> HOT IN ON BTSI BU FUSE 21
