Chevrolet Corvette C5 (1997-2004) fog lamp request Wiring diagram
This page shows the only wiring diagram for the component.fog lamp request, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog lamp request (1 of 1)
ALC HDLP RELAY 44
AMBIENT LIGHT SENSOR (TOP OF DIC SWITCHES)
AMPLIFIER
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON THE TOE BOARD, IN RIGHT FOOTWELL)
DK GRN/WHT WIRE
F/TNK DR FUSE 32
FOG LAMP RELAY CTRL FOG LAMP IND CTRL
FOG LAMP REQUEST
FOG LAMP SWITCH
FOG LAMP/ REAR COMPARTMENT LID RELEASE SWITCH
FOG LEFT FOG LAMP LAMP ON INDICATOR
FOG LP FUSE 6
FOG LP RELAY 39
HDHIBML FUSE 12
HDHIBMR FUSE 9
HDLOBML FUSE 10
HDLOBMR FUSE 8
HDLP CIRCUIT BREAKER 54
HEADLAMP DIMMER SWITCH
HEADLAMP DOORS CIRCUIT
HEADLAMP SWITCH (PART OF MULTIFUNCTION TURN SIGNAL LEVER) FLASH -TO- PASS SWITCH
HIGH BEAM
HIGH LOW
HOT AT ALL TIMES
I/P FUSE BLOCK (RIGHT FRONT FOOT- WELL)
I/P FUSE BLOCK (RIGHT FRONT FOOTWELL)
INSTRUMENT PANEL CLUSTER (IPC) HIGH BEAM INDICATOR
LEFT HEADLAMP DOOR ASSEMBLY
LIGHT SENSOR GROUND CTRL LIGHT SENSOR INPUT CTRL ALC HCLP RELAY 44 CTRL
LOW BEAM
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
OFF HEAD PARK
ORG/ WIRE
ORG/BLK WIRE
PPL
RED WIRE
RIGHT FOG LAMP
RIGHT HEADLAMP DOOR ASSEMBLY
SPLICE
SPLICE PACK
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
