Chevrolet Corvette C5 (1997-2004) compuetr data lines system Wiring diagram
This page shows the only wiring diagram for the component.compuetr data lines system, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram compuetr data lines system (1 of 1)
ANTI-THEFT SYSTEM
BCM CALSS 2 SERIAL DATA
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON THE TOE BOARD, IN RIGHT FOOTWELL)
COMPUETR DATA LINES SYSTEM
CON TOP COVER AJAR SW IN
CON TOP REL COVER SW IN
CON TOP RLY COVER REL CTRL
DK BLU WIRE
DK GRN WIRE
FOLDING TOP LID LATCH (ON STOWAGE LID EXTENSION BRACKET)
FOLDING TOP RELEASE SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
LT GRN WIRE
NCA WIRE
PPL
PPL LT
RED WIRE
SPLICE PACK 302 (FRONT OF RIGHT QUARTER PANEL)
TONN REL FUSE 17
TONN REL RELAY 41
