Chevrolet Corvette C5 (1997-2004) btsi/bu mini fuse 21 Wiring diagram
This page shows the only wiring diagram for the component.btsi/bu mini fuse 21, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram btsi/bu mini fuse 21 (1 of 1)
A/T
ANTI-LOCK BRAKES SYSTEM
APPROACH MINI FUSE 2
BACK-UP LAMP SWITCH (RIGHT SIDE OF TRANSMISSION)
BLK WIRE
BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FRONT FOOTWELL)
BRN WIRE
BTSI/BU MINI FUSE 21
DK BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
INSTRUMENT PANEL FUSE BLOCK (AT RIGHT FRONT FOOTWELL)
LEFT BACK-UP LAMP
LT GRN WIRE
M/T
PARK/NEUTRAL POSITION SWITCH, BACK-UP LAMP SWITCH (ON LEFT SIDE OF TRANSMISSION)
PERIM LP MICRO RELAY 38
RIGHT BACK-UP LAMP
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
Go to component -> Back-up lamps circuit -> BTSI/BU MINI FUSE 21
