Chevrolet Corvette C5 (1997-2004) a/t shift lock control solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. a/t shift lock control solenoid, in which he is found in the car Chevrolet Corvette C5 (1997-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
a/t shift lock control solenoid wiring diagram (1 of 2)
A/T SHIFT LOCK CONTROL SOLENOID
AUTO A/C
BANK 1 SENSOR 1 BANK 1 SENSOR 1
BANK 2 SENSOR 1
BANK 2 SENSOR 2
BASE SEAT
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY (MANUAL A/C)
BODY CONTROL MODULE (BCM)
BOSE RELAY 45
CIGAR LIGHTER
DEFOGGER GRID
ELECTRONIC BRAKE/ CONTROL MODULE (EBTCM)
ENGINE OIL LEVEL SWITCH
F/ PMP MICRO- RELAY 35
FOOTWELL PANEL COURTESY LAMP- RIGHT
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
HVAC CONTROL MODULE
I/P COMPARTMENT LAMP
IGN MINI- RELAY 42
IGNITION COIL/ MODULE 1
IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 3
IGNITION COIL/ MODULE 4
IGNITION COIL/ MODULE 5
IGNITION COIL/ MODULE 6
IGNITION COIL/ MODULE 7
IGNITION COIL/ MODULE 8
IGNITION SWITCH
MANUAL A/C
MANUAL A/C AUTO A/C
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
PASSENGER DOOR MODULE (PDM) DOOR LATCH- RIGHT
POWERTRAIN CONTROL MODULE (PCM)
SEAT BELT SWITCH- DRIVER
SEAT CONTROL MODULE DRIVER
SEAT PUMP DRIVER
SEAT RELAY CENTER DRIVER
SPLICE PACK 122 (UNDER LEFT REAR CORNER OF BATTERY TRAY)
SPLICE PACK 202 (RIGHT KICK PANEL)
SPORT SEAT
THROTTLE ACTUATOR CONTROL (TAC) MODULE
VANITY MIRROR LAMP- LEFT VANITY MIRROR LAMP- RIGHT INSIDE REARVIEW MIRROR
W/ MEMORY
W/O MEMORY
WIRE END TAPED TO INSTRUMENT PANEL HARNESS
Go to component -> Ground distribution circuit (2 of 3) -> A/T SHIFT LOCK CONTROL SOLENOID
a/t shift lock control solenoid wiring diagram (2 of 2)
& IPC FUSE 25
0 (OR 1)
A/T
A/T SHIFT LOCK CONTROL SOLENOID
ALC HDLP RELAY 44
ALC PRK LP RELAY 43
ASRY OFF FUSE 11
BCM A FUSE 9
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BTISBU FUSE 21 BCM 13 FUSE 22
BULB TEST ON
C/LALDL FUSE 29
CLUTCH PEDAL POSITION (CPP) SWITCH
CRK FUSE 14
CTSY LP RELAY 42
DATA LINK CONNECTOR (DLC)
DK BLU WIRE
FROM C/LTR FUSE 7 (DIAGRAM 2 OF 4)
FROM FUSE BLOCK-I/P)
FUSE 23
FUSE BLOCK- UNDERHOOD (ON RIGHT REAR OF ENGINE COMPARTMENT)
FUSE BLOCK-I/P (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD)
HDLP CIRCUIT BREAKER 54
I/P COMPARTMENT LAMP
IGNITION SWITCH
INSIDE REARVIEW MIRROR
INSTRUMENT PANEL CLUSTER (IPC)
LEFT VANITY MIRROR LAMP
M/T
M/T A/T
MONIT- ORED LD FUSE 2
MONITO-
MULTIFUNCTION TURN SIGNAL LEVER
NCA WIRE
OFF
ORG/ WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH
PARK/ NEUTRAL POSITION (PNP) SWITCH BACKUP LAMP SWITCH
PK T/LP FUSE 6
PNK WIRE
PPL
RED LD WIRE
RED WIRE
RELAY 37
RIGHT VANITY MIRROR LAMP
STEERING COLUMN LOCK RELAY
TO FUSE BLOCK-I/P (DIAGRAM 4 OF 4)
TO HVAC FUSE 18 (DIAGRAM 4 OF 4)
UNDERHOOD LAMP
WINDSHIELD WIPER MOTOR WINDSHIELD WIPER/ WASHER SWITCH
WIRE ENDS TAPED TO I/P HARNESS
WSW FUSE 10
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> A/T SHIFT LOCK CONTROL SOLENOID
