Chevrolet Corvette C5 (1997-2004) 60 58 sens gnd data line Wiring diagram
This page shows the only wiring diagram for the component.60 58 sens gnd data line, which is found in the car Chevrolet Corvette C5 (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 60 58 sens gnd data line (1 of 1)
43 18 14 45 17 RELAY CTRL A/C ON PRESS SIG
60 58 SENS GND DATA LINE
A/C CLU RELAY
A/C COMPRESSOR CLUTCH
A/C FUSE 24
A/C REFRIGERANT PRESSURE SENSOR (ATTACHED TO THE A/C HIGH SIDE LINE)
A/C REQ
BLK WIRE
DATA LINK CONNECTOR (DLC) (UNDER DASH, BELOW STEERING COLUMN)
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT IN RUN OR START
HVAC CONTROL MODULE (W/ AUTO A/C)
HVAC CONTROL MODULE (W/ MANUAL A/C)
NCA WIRE
PPL
RED/BLK WIRE
SERIAL DATA
SPLICE PACK
STAR CONNECTOR 1 (IN DASH HARNESS)
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
Go to component -> Compressor circuit -> 60 58 SENS GND DATA LINE
