Chevrolet Corvette C5 (1997-2004) 1 2 3 4 lf low rf low lr low rr low Wiring diagram

1 2 3 4 5 6 7 8 9 10 LF RETURN LF FEED RF RTN RF FEED GROUND RADIO ON 1 2 3 4 5 6 7 8 9 10 LT AUDIO RT AUDIO REM RTN DRAIN RTN BATTERY 1 2 3 4 LF LOW RF LOW LR LOW RR LOW 1 2 DK R ANT IN R ANT IN 11 12 13 14 15 16 17 18 19 20 LEFT AUDIO RT AUDIO REMOTE RTN 372 514 440 BARE ANT IN ANT OUT ANT RLY COIL RF SUB ANTENNA ANTENNA RLY BARE BATTERY BLK WIRE BLK/WHT WIRE BOSE FUSE 28 BOSE RELAY BOSE SIGNAL PROCESSOR (UNDER LEFT SIDE OF DASH, ABOVE ACCEL- ERATOR PEDAL) BRN WIRE BRN/WHT WIRE CD CHANGER REMOTE PLAY- BACK DEVICE COMPUTER DATA LINES SYSTEM COUPE DEFOGGER SYSTEM POWER ANTENNA SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE E, C DATA E, C DATA SERIAL DATA RR RETURN RR FEED LR RETURN LR FEED FACTORY INSTALLED DEALER INSTALLED FC RTN FRONT WINDOW ANTENNA GRN WIRE GROUND GRY WIRE HARNESS) HOT AT ALL TIMES I/P FUSE BLOCK (IN RIGHT FRONT FOOT- WELL, MOUNTED TO TOE BOARD) LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER LR LOW LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MAST ANTENNA NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE POWER ANTENNA SYSTEM RADIO RADIO ANTENNA MODULE (BEHIND LOWER "B" PILLAR TRIM) RADIO ON PNK ARS 1 WIRE RDO/ANT FUSE 24 RDO/CD FUSE 5 REAR WINDOW ANTENNA RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER SPLICE PACK TAN WIRE TAN/BLK WIRE WOOFER AMPLIFIER YEL WIRE
