Starting circuit for Chevrolet Corvette C4 (1984-1998)

Starting circuit

Get access

A/T ACCY BATTERY BLK WIRE BULB TEST CENTRAL CONTROL MODULE (BELOW RADIO CONTROL HEAD) RELAY CONTROL CLUTCH PEDAL POSITION SWITCH (TOP OF CLUTCH PEDAL) FUSIBLE LINK GENERATOR I/P FUSE BLOCK CRANK P/N CLUTCH FUSE 10 IGNITION FUSE 6 IGNITION FUSE 7 IGNITION SWITCH LOCK M/T NCA WIRE OFF POWER DISTRIBUTION SYSTEM PPL PPL A/T M/T PPL PPL PULL- IN COIL HOLD- IN COIL RED WIRE RUN WIRE STARTER MOTOR STARTER SOLENOID THEFT DETERRENT RELAY (LEFT SIDE OF I/P) UNDERHOOD FUSE BLOCK 1 YEL WIRE YEL/BLK WIRE
