6-way power seat circuit for Chevrolet Corvette C4 (1984-1998)
6-way power seat circuit
1995 VFTC
BLK WIRE
BLU WIRE
DOWN
ENTIRE SEAT
ENTIRE SEAT UP
FOR- WARD
FORWARD/ BACK MOTOR
FRONT HEIGHT
FRONT HEIGHT FRONT HEIGHT
FRONT HEIGHT MOTOR
GRN WIRE
HOT AT ALL TIMES POWER SEAT CIRCUIT BREAKER
I/P FUSE BLOCK
LEFT SEAT ADJUSTER SWITCH
LEFT SEAT MOTOR ASSEMBLY
MOTOR
NCA WIRE
ORG/ WIRE
REAR HEIGHT
REAR HEIGHT BACK
REAR HEIGHT FRONT HEIGHT FRONT HEIGHT BACK
REAR HEIGHT MOTOR
REAR HEIGHT MOTOR FORWARD/ BACK MOTOR
RED WIRE
RIGHT SEAT ADJUSTER SWITCH
RIGHT SEAT MOTOR ASSEMBLY
SEAT SWITCH DIODE (UNDER CENTER CONSOLE)
W/ LEFT POWER SEAT ONLY W/ RIGHT POWER SEAT
WHT WIRE
YEL WIRE
