Power mirror circuit for Chevrolet Corvette C4 (1984-1998)
Power mirror circuit
BLK WIRE
GRY/BLK WIRE
HORIZ- ONTAL MOTOR
HORIZ- ONTAL MOTOR VERTICAL MOTOR
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
ILLUMINATION LAMP
INTERIOR LIGHTS SYSTEM (RHEOSTAT CONTROLLED)
LEFT OUTSIDE MIRROR
LT BLU WIRE
LT GRN WIRE
MIRROR POSITION SWITCH DOWN LEFT
MIRROR SELECT SWITCH LEFT MIRROR
NCA WIRE
OUTSIDE REMOTE CONTROL REAR VIEW MIRROR SWITCH
PNK WIRE
POWER MIRROR FUSE 31
PPL
PPL/WHT WIRE
RED/WHT WIRE
RIGHT
RIGHT MIRROR
RIGHT OUTSIDE MIRROR
VERTICAL MOTOR
WHT WIRE
