Backup lamps circuit for Chevrolet Corvette C4 (1984-1998)
Backup lamps circuit
1995 VFTC
A/T
BACKUP FUSE 28
BACKUP LAMPS SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLOCK
HOT IN RUN, BULB TEST OR START
I/P FUSE
LEFT BACKUP CORNERING LAMP
LEFT BACKUP LAMP
LT GRN WIRE
M/T
PNK GEAR LOCKOUT RELAY WIRE
PNK WIRE
RIGHT BACKUP CORNERING LAMP
RIGHT BACKUP LAMP
TRANSMISSION RANGE SWITCH (AT BASE OF GEAR SELECTOR LEVER)
