Defogger circuit, with manual a/c for Chevrolet Corvette C4 (1984-1998)
Defogger circuit, with manual a/c
1995 VFTC I/P FUSE BLOCK
A/C CLUTCH FUSE 18
BLK WIRE
BRN WIRE
CENTRAL CONTROL MODULE (BEHIND CENTER OF I/P) DEFOG CONT. CKT.
CENTRAL CONTROL MODULE (CCM)
COUPE CONVERTIBLE
DEFOG REQUEST INPUT
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK #1 RR DEFOG FUSE 5
HOT IN RUN
HTD MIR FUSE 5
HVAC CONTROL HEAD DEFOG ON LED
HVAC CONTROL HEAD REAR DEFOG ON/OFF SWITCH
I/P FUSE BLOCK
LED DIMMMING CONTROL
LEFT HATCH STRUT
LEFT MIRROR DEFOGGER
NCA WIRE
ORG/ WIRE
PPL
PPL/WHT WIRE
REAR DEFOGGER RELAY
REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER
RED WIRE
RIGHT HATCH STRUT
RIGHT MIRROR DEFOGGER
WHT WIRE
