Chevrolet Corvette C4 (1984-1998) wind- shield wiper/ washer switch assembly Wiring diagram
This page shows the only wiring diagram for the component.wind- shield wiper/ washer switch assembly, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wind- shield wiper/ washer switch assembly (1 of 1)
1995 VFTC
BLK WIRE
BRN WIRE
GRY WIRE
HI MIST LO OFF OFF PULSE DELAY PULSE
HI MIST LO PULSE
HI MIST OFF LO
HOT IN ACCY OR RUN
I/P FUSE BLOCK
LO OFF PULSE
LT BLU WIRE
MECHANICAL ARM
MIST
NCA WIRE
PARK RELAY
PNK WIRE
PPL
SOLID STATE TIMER
WASHER SWITCH
WIND- SHIELD WIPER/ WASHER SWITCH ASSEMBLY
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR ASSEMBLY CONTROL BOARD
WIPER FUSE 3
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> WIND- SHIELD WIPER/ WASHER SWITCH ASSEMBLY
