Chevrolet Corvette C4 (1984-1998) uart data uart data diag enable Wiring diagram
This page shows the only wiring diagram for the component.uart data uart data diag enable, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram uart data uart data diag enable (1 of 1)
29 30 UART DATA UART DATA
BLK WIRE
BLK/WHT WIRE
CENTRAL CONTROL MODULE (CCM) (BEHIND RADIO)
DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P, RIGHT OF STEERING COLUMN)
DIAG ENABLE
DIAGNOSTIC ENERGY RESERVE MODULE (BEHIND RIGHT I/P)
DK BLU/WHT WIRE
DK GRN WIRE
E&C BUS
ELECTRONIC BRAKE/ TRACTION CONTROL MODULE (EBTCM) (LEFT CARGO COMPT)
HOT AT ALL TIMES
HVAC PROGRAMMER (BEHIND I/P, LEFT OF STEERING COLUMN)
I/P FUSE BLOCK
NCA WIRE
ORG/ WIRE
PASSIVE KEYLESS ENTRY MODULE (BEHIND DRIVER INFORMATION CENTER)
POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
PPL
PPL DATA CLSS 2
RADIO CONTROL HEAD UNIT
REAL TIME DAMPING MODULE (LEFT CARGO COMPARTMENT)
RH CTSY FUSE 36
TAN WIRE
UART DATA
UART DATA UART DATA
UART DATA UART DATA DIAG ENABLE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines -> UART DATA UART DATA DIAG ENABLE
