Chevrolet Corvette C4 (1984-1998) throttle position sensor interface module Wiring diagram
This page shows the only wiring diagram for the component.throttle position sensor interface module, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram throttle position sensor interface module (1 of 1)
#1 #2 #3
#8 #5 #3 #2
A/T
AUTO TRANS FUSE 15
AUTOMATIC TRANSMISSION
BACKUP FUSE 28
BACKUP LAMP SWITCH
BLK WIRE
BLOCKOUT RELAY
BRAKE SWITCH ASSEMBLY
CCM 1 FUSE 35
CENTRAL CONTROL MODULE
CLUSTER FUSE 27
COIL FUSE 25
CRUISE CONTROL CUT OFF RELAY
CRUISE FUSE 32
DIAGNOSTIC ENERGY RESERVE MODULE
DRIVER INFORMATION CENTER
DUAL POLE ARMING SENSOR
E.C.M. FUSE 33
ENG 1 FUSE 30
ENG 2 FUSE 21
ENGINE COOLING FAN RELAYS
FAN AIR BAG FUSE 29 FUSE 34
FROM IGNITION SWITCH
FUEL INJECTORS
FUSE 31
GEAR BLOCKOUT RELAY
I/P FUSE BLOCK
IGNITION COIL
IGNITION COIL MODULE
INJ 1 FUSE 22
INJ 2 FUSE 23
INSTRUMENT CLUSTER DIAG- NOSTIC ENERGY RESERVE MODULE
LEFT VANITY MIRROR LAMP RIGHT VANITY MIRROR LAMP LIGHTED REAR VIEW MIRROR
M/T
MASS AIR FLOW SENSOR
NCA WIRE
OUTSIDE REMOTE CONTROL REAR VIEW MIRROR
P.K.E. FUSE 26
PASSIVE KEYLESS ENTRY MODULE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWER MIRROR
POWERTRAIN CONTROL MODULE
SECONDARY AIR INJECTION PUMP RELAY PNK WIRE
SWITCH
THROTTLE POSITION SENSOR INTERFACE MODULE
TO FUEL INJECTORS
TRANS- MISSION RANGE SWITCH
TURN FLASHER
TURN FUSE 24
W/ DRL
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> THROTTLE POSITION SENSOR INTERFACE MODULE
