Chevrolet Corvette C4 (1984-1998) right power window switch Wiring diagram
This page shows the only wiring diagram for the component.right power window switch, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power window switch (1 of 1)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL CONTROL MODULE
CLUSTER FUSE 27
CNSL ILLUM FUSE 13
CONTROL BUTTON LED'S
CONTROL LCD DISPLAY BUTTON LED'S
DEFOG ON LED
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER
ELECT A/C)
FOG LAMP SW, LED
GRY WIRE
GRY/BLK WIRE
HEADLAMP SWITCH
HEATER/ VENT/AIR CONDITIONING CONTROL HEAD
HEATER/VENT/ AIR CONDITIONING CONTROL HEAD
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
HOT W/ DEFOGGER ON I/P FUSE BLOCK HTD MIR FUSE 5
I/P FUSE BLOCK
IGN
INCANDESCENT POWER DRIVER (LEFT OF STEERING COLUMN)
INSTRUMENT CLUSTER
LCD DIMMING CONTROL
LCD DISPLAY
LED DIMMING CONTROL
LH ILLUM FUSE 12
LIGHTED REARVIEW MIRROR LEFT DOOR COURTESY LAMP
MANUAL A/C
MAX HEAD OFF PARK
MIN
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL/WHT WIRE
PRNDL ILLUMINATION
RADIO CONTROL HEAD
RADIO GROUND OUT
RADIO RECEIVER
RADIO RECEIVER BOX RADIO GROUND OUT
RH ILLUM FUSE 11
RIGHT DOOR COURTESY LAMP
RIGHT POWER WINDOW SWITCH
SOLID STATE DRIVER
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> RIGHT POWER WINDOW SWITCH
