Chevrolet Corvette C4 (1984-1998) program request input universal theft deterrent status shield ground Wiring diagram

1995 VFTC 219 218 PPL ANTENNA INPUT KEY-IN- IGNITION INPUT ALL DOORS LOCK OUTPUT ARM UNIVERSAL THEFT DETERRENT BATTERY ARM UNIVERSAL THEFT DETERRENT BLK WIRE BLK/ORG WIRE BLK/WHT WIRE CENTRAL CONTROL MODULE CENTRAL CONTROL MODULE (BEHIND CENTER OF I/P) CONV CONV COUPE COUPE DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P) DIAGNOSTIC ENABLE INPUT DK GRN WIRE DOOR KEY SWITCH OUTPUT SIGNAL DOOR UNLOCK INPUT DRIVER INFORMATION CENTER GROUND ANTENNA INPUT GRY WIRE GRY/BLK WIRE HATCH RELEASE OUTPUT BATTERY DOOR LOCK MOTOR HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INDICATOR CONTROL KEY-IN- IGNITION SWITCH LEFT DOOR AJAR SWITCH LEFT DOOR KEY SWITCH RIGHT DOOR KEY SWITCH LEFT DOOR LOCK MOTOR LEFT DOOR LOCK SWITCH LEFT DOOR UNLOCK OUTPUT LOCK INPUT LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE P.K.E. FUSE 26 PASSIVE KEYLESS ENTRY ANTENNA #1 PASSIVE KEYLESS ENTRY ANTENNA #2 PASSIVE KEYLESS ENTRY INDICATOR PASSIVE KEYLESS ENTRY MODULE (BEHIND CENTER OF I/P) PNK IGNITION LEFT DOOR AJAR INPUT RIGHT DOOR AJAR INPUT WIRE PNK WIRE POWER LOCK FUSE 42 PPL PROGRAM REQUEST INPUT UNIVERSAL THEFT DETERRENT STATUS SHIELD GROUND PROGRAM REQUEST OUTPUT RDO BAT FUSE 40 RED WIRE RIGHT DOOR AJAR SWITCH RIGHT DOOR LOCK MOTOR RIGHT DOOR LOCK SWITCH RIGHT DOOR UNLOCK OUTPUT SHIELD GROUND ANTENNA #1 GROUND TAN WIRE TRUNK RELEASE SYSTEM UNIVERSAL THEFT DETERRENT STATUS UNLOCK INPUT YEL WIRE
